MR Current Transformer
MR Current Transformer
Product Description

 The  Standard Sillicon Steel core Models MR Current Transformer is for measuring current transformers.

2. The accuracy class is designed by the highest permissible percentage current (ratio) error at the rated current

      perscribed for the accuracy class concerned.

3. The  Electronic Transformer s the standard sillicon steel core models,tape wrapping current transformer, low cost.

4. The   current transformer for meter can be used with or without foot and plastic cover.

5. it complies to IEC60044-1,GB1208-2006



Specifications





Model Rated current (A) Rated power (VA)
Class:0.5 Class:1
MR-28 30/5
50/5   1.5
60/5   1.5
75/5   1.5
100/5 1.5 2.5
MR-42 100/5 1.5 2.5
150/5 1.5 2.5
200/5 2.5 5
250/5 3.75 5
300/5 3.75 5
MR-65 100/5 5 5
500/5 5 5
600/5 5 10
750/5 5 10
MR-85 750/5 5 10
800/5 10 10
1000/5 10 15
1200/5 10 15
1250/5 10 15
1500/5 10 15
1600/5 10 15
MR-125 1000/5 10 15
1200/5 10 15
1500/5 10 15
1600/5 10 15
2000/5 15 15
2500/5 15 15
3000/5 15 15
3500/5 15 15
4000/5 15 15





Primary current: 30A-5000A
Secondary current: 5A, 1A
Standard approval: IEC44-1,IEC185,BS7626
Maximum voltage: 0.72KV
Frequency: 50-60Hz
Rated load: 5VA-15VA
Class: 3.0,1.0,0.5
Short-time thermal current: Ith=60 X Ih
Rated security coefficient: FS<5
