Product Center > Panel Meter > Digital DC&Volt Meter > Digital DC Meter
Digital DC Meter
Digital DC Meter
Product Name    Square model digital dc ammeter

Category    Digital A.C. Ammeters > DP-Z96A Z72A Z48A

Model   DP-Z96A






DP-Z96A DP-Z72A DP-Z48A DC Ammeters

Accuracy class:±0.5%±bytes

For through current:0.1A 0.5A 1A 1.5A 2A 3A 4A 5A

For transformation ratio:1-9999A or 1-9999KA to be set freely.The meters should be used with a shut of which external secondary voltage is 60mVor 75mV.

Overload rate of ammeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

For through voltage:50V 100V 200V 300V 400V 500V 600V.

For transformation ratio:1-9999V or 1-9999KV to be set freely.to be used with external DC shunt.

Overload rate of voltmeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

Rated auxiliary power supply:AC110V AC 220V AC 380V AC/DC48-250V Frequency 50/60HZ.

Specific features:Four series of buttons are set outside of the faceplate.Users can set the transformation ration specification of the shunt and voltage divider on their own.

Product performance:All the meters are equipped with black silk-screen printing PVC faceplate.The movement consists of industrial programmable chip and high-quality components so that it is of good adaptation to the conditions.The case is made of PC plastics,of which the resistant temperature can be up to 120°C.The resistant voltage is higher than 2000V.The meter is easy to install with high-strength plastics pieces by pushing so that it is of high immobility.

Product Name    Square model digital alarm dc ammeter

Category    Digital A.C. Ammeters > DP-ZB96A ZB72A ZB48A

Model   DP-ZB96A






DP-ZB96A DP-ZB72A DP-ZB48A DC Ammeters

Accuracy class:±0.5%±bytes

For through current:0.1A 0.5A 1A 1.5A 2A 3A 4A 5A

For transformation ratio:1-9999A or 1-9999KA to be set freely.The meters should be used with a current transformer of which external secondary current is 1A or 5A.

Overload rate of ammeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

For through voltage:50V 100V 200V 300V 400V 500V 600V.

For transformation ratio:1-9999V or 1-9999KV to be set freely.The meters should be used with a voltage transformer of which external secondary voltage is100V.

Overload rate of voltmeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

Rated auxiliary power supply:AC110V AC 220V AC 380V AC/DC48-250V Frequency 50/60HZ.

Specific features:Four series of buttons are set outside of the faceplate.Users can set the alarm parameters and the transformation ration specification of the mutual inductor on their own.

Product performance:All the meters are equipped with black silk-screen printing PVC faceplate.The movement consists of industrial programmable chip and high-quality components so that it is of good adaptation to the conditions.The case is made of PC plastics,of which the resistant temperature can be up to 120°C.The resistant voltage is higher than 2000V.The meter is easy to install with high-strength plastics pieces by pushing so that it is of high immobility.

Product Name    Torque type digital dc ammeter

Category    Digital A.C. Ammeters > DP-Z96X48A Z72X36A

Model   DP-Z96X48A   DP-Z72X36A




DP-Z96X48A DP-Z72X36A DC Ammeters

Accuracy class:±0.5%±bytes

For through current:0.1A 0.5A 1A 1.5A 2A 3A 4A 5A

For transformation ratio:1-9999A or 1-9999KA to be set freely.The meters should be used with a shut of which external secondary voltage is 60mVor 75mV.

Overload rate of ammeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

For through voltage:50V 100V 200V 300V 400V 500V 600V.

For transformation ratio:1-9999V or 1-9999KV to be set freely.to be used with external DC shunt.

Overload rate of voltmeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

Rated auxiliary power supply:AC110V AC 220V AC 380V AC/DC48-250V Frequency 50/60HZ.

Specific features:Four series of buttons are set outside of the faceplate.Users can set the transformation ration specification of the shunt and voltage divider on their own.

Product performance:All the meters are equipped with black silk-screen printing PVC faceplate.The movement consists of industrial programmable chip and high-quality components so that it is of good adaptation to the conditions.The case is made of PC plastics,of which the resistant temperature can be up to 120°C.The resistant voltage is higher than 2000V.The meter is easy to install with high-strength plastics pieces by pushing so that it is of high immobility.

Product Name    Torque type digital alarm dc ammeter

Category    Digital A.C. Ammeters > DP-ZB96X48A ZB72X36A

Model   DP-ZB96X48A   DP-ZB72X36A






DP-ZB96X48A DP-ZB72X36A DC Ammeters

Accuracy class:±0.5%±bytes

For through current:0.1A 0.5A 1A 1.5A 2A 3A 4A 5A

For transformation ratio:1-9999A or 1-9999KA to be set freely.The meters should be used with a current transformer of which external secondary current is 1A or 5A.

Overload rate of ammeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

For through voltage:50V 100V 200V 300V 400V 500V 600V.

For transformation ratio:1-9999V or 1-9999KV to be set freely.The meters should be used with a voltage transformer of which external secondary voltage is100V.

Overload rate of voltmeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

Rated auxiliary power supply:AC110V AC 220V AC 380V AC/DC48-250V Frequency 50/60HZ.

Specific features:Four series of buttons are set outside of the faceplate.Users can set the alarm parameters and the transformation ration specification of the mutual inductor on their own.

Product performance:All the meters are equipped with black silk-screen printing PVC faceplate.The movement consists of industrial programmable chip and high-quality components so that it is of good adaptation to the conditions.The case is made of PC plastics,of which the resistant temperature can be up to 120°C.The resistant voltage is higher than 2000V.The meter is easy to install with high-strength plastics pieces by pushing so that it is of high immobility.
