Product Center > Panel Meter > Digital AC&Volt Meter > Digital AC Meter
Digital AC Meter
Digital AC Meter
Product Name    Square model digital ac current meter

Category    Digital A.C. Ammeters > DP-J96A J72A J48A

Model   DP-J96A   DP-J72A   DP-J48A






DP-J96A DP-J72A DP-J48A AC Ammeters

Accuracy class:±0.5%±bytes

For through current:0.1A 0.5A 1A 1.5A 2A 3A 4A 5A

For transformation ratio:1-9999A or 1-9999KA to be set freely.The meters should be used with a current transformer of which external secondary current is 1A or 5A.

Overload rate of ammeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

For through voltage:50V 100V 200V 300V 400V 500V 600V.

For transformation ratio:1-9999V or 1-9999KV to be set freely.The meters should be used with a voltage transformer of which external secondary voltage is100V.

Overload rate of voltmeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

Rated auxiliary power supply:AC110V AC 220V AC 380V AC/DC48-250V Frequency 50/60HZ.

Specific features:Four series of buttons are set outside of the faceplate.Users can set the transformation ration specification of the mutual inductor on their own.

Product performance:All the meters are equipped with black silk-screen printing PVC faceplate.The movement consists of industrial programmable chip and high-quality components so that it is of good adaptation to the conditions.The case is made of PC plastics,of which the resistant temperature can be up to 120°C.The resistant voltage is higher than 2000V.The meter is easy to install with high-strength plastics pieces by pushing so that it is of high immobility.

Product Name    Digital alarm ac current meter square

Category    Digital A.C. Ammeters > DP-JB96A JB72A JB48A

Model   DP-JB96A






DP-JB96A DP-JB72A DP-JB48A AC Ammeters

Accuracy class:±0.5%±bytes

For through current:0.1A 0.5A 1A 1.5A 2A 3A 4A 5A

For transformation ratio:1-9999A or 1-9999KA to be set freely.The meters should be used with a current transformer of which external secondary current is 1A or 5A.

Overload rate of ammeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

For through voltage:50V 100V 200V 300V 400V 500V 600V.

For transformation ratio:1-9999V or 1-9999KV to be set freely.The meters should be used with a voltage transformer of which external secondary voltage is100V.

Overload rate of voltmeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

Rated auxiliary power supply:AC110V AC 220V AC 380V AC/DC48-250V Frequency 50/60HZ.

Specific features:Four series of buttons are set outside of the faceplate.Users can set the alarm parameters and the transformation ration specification of the mutual inductor on their own.

Product performance:All the meters are equipped with black silk-screen printing PVC faceplate.The movement consists of industrial programmable chip and high-quality components so that it is of good adaptation to the conditions.The case is made of PC plastics,of which the resistant temperature can be up to 120°C.The resistant voltage is higher than 2000V.The meter is easy to install with high-strength plastics pieces by pushing so that it is of high immobility.

Product Name    Torque type digital ac current meter

Category    Digital A.C. Ammeters > DP-J96X48A J72X36A

Model   DP-J96X48A   DP-J72X36A






DP-J96X48A DP-J72X36A AC Ammeters

Accuracy class:±0.5%±bytes

For through current:0.1A 0.5A 1A 1.5A 2A 3A 4A 5A

For transformation ratio:1-9999A or 1-9999KA to be set freely.The meters should be used with a current transformer of which external secondary current is 1A or 5A.

Overload rate of ammeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

For through voltage:50V 100V 200V 300V 400V 500V 600V.

For transformation ratio:1-9999V or 1-9999KV to be set freely.The meters should be used with a voltage transformer of which external secondary voltage is100V.

Overload rate of voltmeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

Rated auxiliary power supply:AC110V AC 220V AC 380V AC/DC48-250V Frequency 50/60HZ.

Specific features:Four series of buttons are set outside of the faceplate.Users can set the transformation ration specification of the mutual inductor on their own.

Product performance:All the meters are equipped with black silk-screen printing PVC faceplate.The movement consists of industrial programmable chip and high-quality components so that it is of good adaptation to the conditions.The case is made of PC plastics,of which the resistant temperature can be up to 120°C.The resistant voltage is higher than 2000V.The meter is easy to install with high-strength plastics pieces by pushing so that it is of high immobility.

Product Name    Torque type digital alarm ac current meter

Category    Digital A.C. Ammeters > DP-JB96X48A JB72X36A

Model   DP-JB96X48A   DP-JB72X36A






DP-JB96X48A DP-JB72X36A AC Ammeters

Accuracy class:±0.5%±bytes

For through current:0.1A 0.5A 1A 1.5A 2A 3A 4A 5A

For transformation ratio:1-9999A or 1-9999KA to be set freely.The meters should be used with a current transformer of which external secondary current is 1A or 5A.

Overload rate of ammeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

For through voltage:50V 100V 200V 300V 400V 500V 600V.

For transformation ratio:1-9999V or 1-9999KV to be set freely.The meters should be used with a voltage transformer of which external secondary voltage is100V.

Overload rate of voltmeters:1.1.2times,”HHHH”means beyond overload and “----”means beyond range.

Rated auxiliary power supply:AC110V AC 220V AC 380V AC/DC48-250V Frequency 50/60HZ.

Specific features:Four series of buttons are set outside of the faceplate.Users can set the alarm parameters and the transformation ration specification of the mutual inductor on their own.

Product performance:All the meters are equipped with black silk-screen printing PVC faceplate.The movement consists of industrial programmable chip and high-quality components so that it is of good adaptation to the conditions.The case is made of PC plastics,of which the resistant temperature can be up to 120°C.The resistant voltage is higher than 2000V.The meter is easy to install with high-strength plastics pieces by pushing so that it is of high immobility.
